ORFS MALE



  • Type: Standard
  • Connector Gender: Male
  • Thread: ORFS
  • Elbow: Straight
Loading...

Description

Complete range of mild steel high pressure hydraulic hose inserts for flexible hydraulic hoses in accordance with the standards ISO 12151 SAE J516. Wide variety of threads, types and sizes.

SKUD.N.Hose SizeDiamThreadPressurePriceStockBuy
0487251634-161" / 25.4mm25.4mm1.7/16"280 bar 4061 psi 17.61 + vat

In stock

0487252042-201 1/4" / 31.8mm31.8mm1.11/16"210 bar 3046 psi 23.76 + vat

In stock

0487250517-55/16" / 7.9mm7.9mm11/16"350 bar 5075 psi 3.74 + vat

In stock

0487250617-63/8" / 9.5mm9.5mm11/16"445 bar 6454 psi 6.15 + vat

In stock

0487250621-63/8" / 9.5mm9.5mm13/16"445 bar 6454 psi 6.74 + vat

In stock

0487250830-81/2" / 12.8mm12.8mm1.3/16415 bar 6019 psi 15.87 + vat

In stock

0487250825-81/2" / 12.8mm12.8mm1"415 bar 6019 psi 13.94 + vat

In stock

0487250821-81/2" / 12.8mm12.8mm13/16"415 bar 6019 psi 8.89 + vat

In stock

0487251030-105/8" / 16mm16.0mm1.3/16350 bar 5075 psi 5.62 + vat

In stock

0487251025-105/8" / 16mm16.0mm1"350 bar 5075 psi 4.85 + vat

In stock

0487251234-123/4" / 19mm19.0mm1.7/16"350 bar 5075 psi 15.65 + vat

In stock

0487251230-123/4" / 19mm19.0mm1.3/16350 bar 5075 psi 7.52 + vat

In stock

0487250417-41/4" / 6.4mm6.4mm11/16"450 bar 6526 psi 9.70 + vat

In stock

0487250414-41/4" / 6.4mm6.4mm9/16"450 bar 6526 psi 5.67 + vat

In stock
