PUSH PULL COUPLER M22 LONG BODY

  • Standard: ISO 7241 A
  • Sleeve: double acting
  • Occlusion: decompression valve
  • Locking: radial balls
  • Material: steel
  • Finishing: Zn-Fe (Cr III)
  • Threads: BSP – NPT – SAE – METRICS
  • Standard seals: NBR
  • Working temperature: -25 °C +100 °C
  • Optional seals: FKM, EPDM or more
  • Working pressure: 250 bar
  • Connection under residual pressure: allowed (both male and female side)
  • Max residual pressure: 250 bar
Loading...

Description

Selection of durable, high quality quick release hydraulic couplings for various applications.

SKUGenderThreadISOMax Working PressureMax Flow RateMin Burst PressurePriceStockBuy
PPK4.1322.222FemaleM22 X 1.5 MALE12.5250 bar90 l/min1300 bar 80.49 + vat

Out of stock
