DOUBLE PILOT OPERATED CHECK VALVE

TYPE: VBPDE

Use and Operation
Pilot check valves are used to block the cylinder in both directions. Flow is free in one direction and blocked in the reverse direction until pilot pressure is applied.

Materials and Features

  • Body: zinc-plated steel
  • Internal Parts: hardened and ground steel
  • Seals: BUNA N standard
  • Poppet Type: any leakage

Applications
Connect V1 and V2 to the pressure flow and C1 and C2 to the actuator.

Loading...

Description

Wide range of superior quality hydraulic valves designed to suit a wide range of applications.

Delivering unsurpassed quality performance and high efficiency.

Exceptionally durable in even the most demanding industrial and mobile applications.

SKUValve typePilot RatioMax Flow RateMax Working PressureCracking PressurePriceStockBuy
V0070VBPDE 1/2"1 : 470 l/min350 bar3.5 bar 62.85 + vat

In stock

V0050VBPDE 3/8"1 : 545 l/min350 bar8 bar 51.54 + vat

In stock

V0020VBPDE 3/8" L1 : 5,535 l/min350 bar3 bar 46.77 + vat

In stock
