METRIC FEMALE 24° CONE – S TYPE (HEAVY)



  • Type: Standard
  • Connector Gender: Female
  • Thread: DIN
  • Elbow: Straight
Loading...

Description

Complete range of mild steel high pressure hydraulic hose inserts for flexible hydraulic hoses in accordance with the standards ISO 12151 SAE J516. Wide variety of threads, types and sizes.


SKUD.N.Hose SizeDiamThreadPressurePriceStockBuy
0423240416-41/4" / 6.4mm6.4mmM16 x 1.5450 bar 6526 psi 2.86 + vat

In stock

0423241236-123/4" / 19mm19.0mmM36 x 2350 bar 5075 psi 8.89 + vat

In stock

0423241636-161" / 25.4mm25.4mmM36 x 2280 bar 4061 psi 12.10 + vat

In stock

0423241645-161" / 25.4mm25.4mmM42 x 2280 bar 4061 psi 21.77 + vat

In stock

0423242052-201 1/4" / 31.8mm31.8mmM52 x 2210 bar 3046 psi 27.50 + vat

In stock

0423242452-241 1 /2"/ 38.1mm38.1mmM52 x 2185 bar 2683 psi 27.50 + vat

In stock

0423241230-123/4" / 19mm19.0mmM30 x 2350 bar 5075 psi 8.89 + vat

In stock

0423241030-105/8" / 16mm16.0mmM30 x 2350 bar 5075 psi 7.88 + vat

In stock

0423240824-81/2" / 12.8mm12.8mmM24 x 1.5420 bar 6091 psi 4.85 + vat

In stock

0423240520-55/16" / 7.9mm7.9mmM20 x 1.5350 bar 5075 psi 3.57 + vat

In stock

0423240518-55/16" / 7.9mm7.9mmM18 x 1.5350 bar 5075 psi 2.37 + vat

In stock

0423240622-63/8" / 9.5mm9.5mmM22 x 1.5450 bar 6526 psi 3.57 + vat

In stock

0423240620-63/8" / 9.5mm9.5mmM20 x 1.5450 bar 6526 psi 3.66 + vat

In stock

0423240618-63/8" / 9.5mm9.5mmM18 x 1.5450 bar 6526 psi 3.57 + vat

In stock

0423240420-41/4" / 6.4mm6.4mmM20 x 1.5450 bar 6526 psi 2.33 + vat

In stock

0423240418-41/4" / 6.4mm6.4mmM18 x 1.5450 bar 6526 psi 2.81 + vat

In stock

0423240414-41/4" / 6.4mm6.4mmM14 x 1.5450 bar 6526 psi 4.70 + vat

In stock
