P80 SERIES MONOBLOCK CONTROL VALVES

Nominal flow rate: 80 liter/min
Max. Pressure: P: 315 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool), different spool options
Number of spools: From 1 to 6
Leakage: 6 cm3/min at 100 bar (From A,B to T)
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638

Loading...

Description

Top quality directional control valves to suit a wide range of applications, delivering unsurpassed quality performance and high efficiency. Directional control valves are one of the core elements in a hydraulic system. They help directing the fluid to different components in the system.

SKUValve typeLeversFlow RateMax Pressure P portPriceStockBuy
P80-6P80 – 6 BANK680 l/min315 bar 531.55 + vat

2 in stock

P80-5P80 – 5 BANK580 l/min315 bar 546.74 + vat

12 in stock

P80-4BANKP80 – 4 BANK480 l/min315 bar 455.62 + vat

38 in stock

P80-3BANKP80 – 3 BANK380 l/min315 bar 334.12 + vat

41 in stock

P80-2BANKP80 – 2 BANK280 l/min315 bar 230.84 + vat

27 in stock

P80-1BANKP80 – 1 BANK180 l/min315 bar 151.87 + vat

26 in stock
